Cloud-Sellers® TJB Steam Injector, TJB
Model
TJB
Cloud-Sellers® TJB Steam Injector
Model Specifications
Liquid Discharge Flow Rate Range15 - 129 l/min
Material CompositionBrass with 316 Stainless Steel Detergent Tube and EP O'Ring
Water Inlet Connection Size1-1/4 in
Water Inlet Connection GenderMale
Steam Inlet Connection Size1-1/4 in
Steam Inlet Connection GenderMale
General Information
Description
- Ideal feed device for tank cleaning machines and custom-designed nozzle manifolds.
- Non-intrusive — suitable for use with cold, low-pressure city water and existing plant steam.
- Produces a high-pressure, high-temperature liquid discharge stream.
- Increased pressure provides higher impact for cleaning tough residues.
- Higher temperature speeds cleaning by quickly breaking down soil.
- Eliminates the need for expensive pumps and heat exchangers.
- Built-in overflow valve ensures safe operation.
- Provides chemical injection via a liquid control valve that siphons chemicals or detergents to maximize cleaning efficiency.
Specification Summary
Liquid Discharge Flow Rate Range
15 - 129 l/min
Material Composition
Brass with 316 Stainless Steel Detergent Tube and EP O'Ring
Steam Inlet Connection Gender
Male
Steam Inlet Connection Size
1-1/4 in
Water Inlet Connection Gender
Male
Water Inlet Connection Size
1-1/4 in
