Air Atomizing Setup, SUVM67B-SS
Images are representative.
Images are representative. Products may differ in material or configuration.
General Information
Description
Air Atomizing Setup
Specification Summary
Liquid Flow Rate Range
1.59 - 7.27 l/h
Material Composition
303 Stainless Steel
Spray Pattern
Variable Spray
Product Type
Set-up
Product Downloads
Product Performance
Liquid Flow Rate
Atomizing Air Flow Rate
Fan Air Flow Rate
Specifications
Configuration
Air Cap Component
VMA67255-60-SS
Fluid Cap Component
VMF1650-SS
Material Composition
303 Stainless Steel
Model
VMAU Air Atomizing Setups
Setup Mix Type
External Mix
Setup Type
Pressure Spray Product
Product Type
Set-up
Performance
Atomizing Air Flow Rate
16.4 nlpm @ 0.69 bar, 20.7 nlpm @ 1.03 bar, 23.8 nlpm @ 1.38 bar, 31.1 nlpm @ 2.07 bar, 36.8 nlpm @ 2.76 bar, 45.3 nlpm @ 3.45 bar, 51 nlpm @ 4.14 bar, 56.6 nlpm @ 4.83 bar, 65.1 nlpm @ 5.52 bar, 70.8 nlpm @ 6.21 bar
Fan Air Flow Rate
57 nlpm @ 0.69 bar, 74 nlpm @ 1.03 bar, 88 nlpm @ 1.38 bar, 110 nlpm @ 2.07 bar, 130 nlpm @ 2.76 bar, 164 nlpm @ 3.45 bar, 187 nlpm @ 4.14 bar, 212 nlpm @ 4.83 bar, 235 nlpm @ 5.52 bar, 255 nlpm @ 6.21 bar
Sales Part Numbers
Air Cap Part Number
VMA67255-60-SS
Fluid Cap Part Number
VMF1650-SS
Standard Feature
Liquid Flow Rate Range
1.59 - 7.27 l/h
Spray Pattern
Variable Spray
