WhirlJet® Nozzle, Brass, 1/2BA-30

• Hollow cone spray pattern
• In-line versions ideal for dust control in mining operations
• BD versions have a lower profile projection for installation in a tee or pipe header
• In-line BDM features recessed orifice area to protect from damage; self-locking cap to prevent loss due to vibration; fiberglass-reinforced nylon inlet body
• BA offset style ideal for installations with physical space limitations
• Spray angles: Standard – 43° to 94°, Wide – 102° to 125°
• Deflected spray versions available with 120°, 150° and 180°included angle of spray at 10 psi (0.7 bar)
• Uniform spray distribution from .11 to 38 gpm (.41 to 145 lpm)
• Operating pressures up to 500 psi (35 bar)

Liquid passes through a hole on the inlet side of the nozzle. The liquid then enters a whirlchamber where it spins in a circle at high speed. The rotation forces the liquid away from the center toward the edges. This causes the liquid to exit the orifice in a hollow cone pattern.
