QuickVeeJet® Nozzle, Brass, 1/4QJJS+QSVV-000021
Images are representative.
Images are representative. Products may differ in material or configuration.
Product Configuration
Inlet Connection Size:1/4 in
Inlet Connection Thread Type:NPT
Inlet Connection Type:Threaded (Male NPT) + Quick-Connect
Material Composition:Brass
General Information
Description
- Ideal for high-maintenance operations – bodies remain on pipe/header; quick quarter-turn removes/installs spray tips in seconds
- Automatic alignment feature saves time
- Miniature versions are ideal when smaller physical size and lower weight are important
- Flat fan type, tapered edge spray pattern
- Spray angles from 0° to 110°
- Uniform spray distribution with flow rates from .035 to 68 gpm (.14 to 255 lpm)
- Operating pressures up to 300 psi (20 bar)
- Choice of metal or ProMax. ProMax features:
- ProMax material, a special grade of polypropylene, resists build-up and chemical attack; for use up to 150 psi (10 bar)
- Internal O-ring provides a positive seal between the body and tip; seal remains attached to tip eliminating accidental loss
- Optional external O-ring protects nozzle from contaminants
- Tips are color-coded for easy flow rate identification
Specification Summary
Inlet Connection Gender
Male
Male
Inlet Connection Size
1/4 in
1/4 in
Inlet Connection Thread Type
NPT
NPT
Inlet Connection Type
Threaded (Male NPT) + Quick-Connect
Threaded (Male NPT) + Quick-Connect
Liquid Flow Rate Range
0.026 - 0.197 l/min
0.007 - 0.052 gpm
Liquid Pressure Range
0.4 - 20 bar
5 - 300 psi
Material Composition
Brass
Brass
Relative Drop Size Range
100 - 500 µm
100 - 500 µm
Spray Pattern
Solid Stream
Solid Stream
Product Type
Nozzle Assembly
Nozzle Assembly
Product Downloads
Product Performance
Liquid Flow Rate
Spray Angle
Specifications
Configuration
Body Type
QJJS
QJJS
Capacity Size
0021
0021
Inlet Connection Gender
Male
Male
Inlet Connection Size
1/4 in
1/4 in
Inlet Connection Thread Type
NPT
NPT
Inlet Connection Type
Threaded (Male NPT) + Quick-Connect
Threaded (Male NPT) + Quick-Connect
Liquid Flow Rate at Rated Pressure
0.087 l/min
0.023 gpm
Material Composition
Brass
Brass
Model
QSVV
QSVV
Spray Angle at Rated Pressure
0°
0°
Tip Type
QSVV
QSVV
Product Type
Nozzle Assembly
Nozzle Assembly
Drop Sizes
Relative Drop Size Group
100 - 500 µm (Light Rain)
100 - 500 µm (Light Rain)
Performance
Spray Angle Range
0 - 0°
0 - 0°
Spray Angle
0° @ 2.758 bar, 0° @ 1.5 bar
0° @ 40 psi, 0° @ 20 psi
Product Category
Brand
Quick VeeJet®
Quick VeeJet®
Spray Angle Catalog Code
Standard
Standard
Sales Part Numbers
Body Sales Part Number
1/4QJJS
1/4QJJS
Tip Sales Part Number
QSVV-000021
QSVV-000021
Standard Feature
Equivalent Orifice Diameter
0.33 mm
0.013 in
Liquid Flow Rate Range
0.026 - 0.197 l/min
0.007 - 0.052 gpm
Liquid Pressure Range
0.4 - 20 bar
5 - 300 psi
Rated Pressure
2.76 bar
40 psi
Relative Drop Size Range
100 - 500 µm
100 - 500 µm
Spray Pattern
Solid Stream
Solid Stream
Weight
0.03 kg
1 oz
