PulsaJet® Electrically-Actuated Hydraulic Nozzle with Flow up to 1.6 gpm and Max Speed 5,000 cpm

* Typical flow range: 0.02 - 1.6 gpm (0.075 - 6.1 lpm)
* Highest capacity PulsaJet nozzle
* Construction: Stainless steel, Viton® or EPDM seals, PPS and PEEK

Automatic Electrically-Actuated Hydraulic Nozzle

Electrically-Actuated / Hydraulic Atomizing nozzles use only liquid pressure as the force for atomization and they provide the fastest cycling of any automatic nozzles – up to 25,000 cycles per minute. PulsaJet® nozzles available with food-grade materials of construction, sanitary connections, liquid recirculation and temperature control for spraying viscous liquids. When paired with an AutoJet® spray controller, these nozzles offer Precision Spray Control (PSC), ensuring consistent application rates at varying line speeds and enabling low flow rates which are comparable to air atomizing nozzles.

Automatic Electrically-Actuated Hydraulic Nozzle, AA10000AUH-10
