* TTI60 produces two 110° wide angle, flat spray patterns for uniform coverage in broadcast applications.
* Extremely large drift resistant droplets are produced through the use of a venturi air aspirator.
* Provides excellent drift control and produces minimal driftable fines — less than 1.5%.
* 60° angle between leading and trailing patterns for increased canopy penetration and leaf coverage.
* All in one molded nozzle and Quick TeeJet® cap design provides automatic spray alignment.
* Removable pre-orifice allows for disassembly and cleaning.
* Available in seven VisiFlo® Polymer (VP) capacities.

TTI TwinJet® Twin Flat Spray

TTI TwinJet® Twin Flat Spray, TTI60

Model Specifications

General Information

Description

Specification Summary

Alternative Models
