* Excellent for application of liquid fertilizer on bare ground or in standing crop.
* Three-stream pattern is ideal for directed application.
* Three solid streams of equal velocity and capacity.
* Offered in a variety of sizes for a wide range of application rates.
* VisiFlo® color-coding for easy capacity identification.
* All acetal construction for excellent chemical resistance.
* Solid stream pattern minimizes leaf burn and virtually eliminates drift.
* Equally spaced distribution at 20" height.
* Use with Quick TeeJet® 114443A-*-CELR cap and gasket.

StreamJet SJ3 Multiple Solid Stream

StreamJet SJ3 Multiple Solid Stream, SJ3

Model Specifications

General Information

Description

Specification Summary

Alternative Models
