QuickMist® Quick Connect Air Atomizing Nozzles

Electrically-Actuated / Hydraulic Atomizing

Throttling and Pressure Relief/Regulating Valves

* Same features as QJ360C multiple nozzle bodies.
* Body designed to fit into standard cam lever couplings allowing for quick change to smaller capacity spray tips.
* Locating nib keeps body properly oriented in fitting.
* Flow Rate: 2.25 GPM at 5 PSI pressure drop, 3.18 GPM at 10 PSI pressure drop.
* 1.26" diameter tip body fits ¾" cam lever coupling.

Multiple Nozzle Bodies For Wet Booms, QC365

Model Specifications

General Information

Description

Specification Summary

Alternative Models
