TankJet® Fluid-Driven Turbine Tank Cleaner, Tanks up to 25 ft., 360° Spray Coverage, Sanitary Design, TJ78M
Model
TJ78M
TankJet® Fluid-Driven Turbine Tank Cleaner, Tanks up to 25 ft., 360° Spray Coverage, Sanitary Design
Model Specifications
Operating PrincipleFluid-driven Turbine
Material Composition316L stainless steel, PTFE and EPDM, All MATs meet FDA Title 21 CFR
Product TypeNozzle
Design FeatureIs Clean In Place
Maximum Recommended Tank DiameterUp to 25 ft
Impact GroupHigh Impact
Design Feature3-A Sanitary Standards
Spray Coverage360°
Minimum Tank Opening5.75 in
Liquid Flow Rate Range13 - 37 gpm
Model Configurator
Step 1 of 2
What is the required inlet connection size?
Standard hydraulic nozzles range in connection size from 1/8” threaded nozzles up to those with 12” flange connections. Larger connection sizes typically have larger flow rates but a wide variety of configurations are available to meet your application needs.
Make selections to see matching products
General Information
Description
These sanitary units enable superior, high-impact cleaning with CIP convenience. They are ideal for milk, cheese and yogurt tanks; spray drying towers; food processing vats and tanks; blenders; brewery tankers; and wine vats.
- High-impact 360° coverage ensures tank cleanliness and results in shorter cleaning cycles and reduced use of water and chemicals.
- Patented sanitary design meets 3-A Sanitary Standard 78.
- Fast and easy maintenance without tools.
- Easy retrofit for spray balls.
- Choice of two- or four-nozzle configurations and inlet connection size.
- Can be steam-sanitized.
Specification Summary
Design Feature
Is Clean In Place, 3-A Sanitary Standards
Impact Group
High Impact
Liquid Flow Rate Range
13 - 37 gpm
Material Composition
316L stainless steel, PTFE and EPDM, All MATs meet FDA Title 21 CFR
Maximum Recommended Tank Diameter
Up to 25 ft
Minimum Tank Opening
5.75 in
Operating Principle
Fluid-driven Turbine
Product Type
Nozzle
Spray Coverage
360°
